Tektronix CR125A 12.5 Gb/s Clock Recovery Instrument

The Tektronix CR125A is a versatile clock recovery instrument designed to support high-speed digital communications up to 12.5 Gb/s. This instrument is essential for accurate clock recovery in testing and validation processes for various high-speed serial data standards.

Key Features:

• Wide Data Rate Support: Operates from 150 Mb/s to 12.5 Gb/s, making it suitable for a range of high-speed communication applications.
• Advanced Jitter Analysis: Provides detailed jitter measurements, including frequency-gated and duty cycle-dependent jitter analysis, helping to isolate jitter sources and measure total jitter accurately.
• Adjustable Loop Bandwidth: Offers variable loop bandwidth from 100 kHz to 12 MHz, with an option to extend up to 24 MHz, allowing precise control over the clock recovery process.
• High Sensitivity: Capable of recovering clocks from signals with low amplitudes, ensuring reliable performance even in challenging conditions.
• Built-in Equalization: Includes linear equalization to recover clocks under difficult conditions such as closed-eye signals, making it suitable for environments with significant inter-symbol interference (ISI).

Technical Specifications:

• Input Data Rate Coverage: 150 Mb/s to 12.5 Gb/s
• Input Sensitivity: 100 mV (single-ended), 50 mV (differential)
• Loop Bandwidth: 100 kHz to 12 MHz (extendable to 24 MHz)
• Interfaces: Compatible with various Tektronix sampling modules and external clock recovery instruments

This unit is in good working condition and is tested to OEM critical specifications. Comes with a 30 day warranty, and we also offer a 7 day right of return (restocking fee may apply). We have been in business for over 25 years, our main focus is customer satisfaction by providing the highest quality of new or used test equipment. Please let us know if you have any questions.

We offer fast domestic and international shipping. We can ship on your FedEx, UPS, or DHL account upon request.  Lead time is typically 1-3 business days. Overseas customers, please consider duty’s and taxes before purchasing

We accept PayPal, Credit Cards, Wire Transfers, Checks, and NET Terms (select and approved customers only).
