Rohde and Schwarz ZVAX-TRM40 TRM Extension Unit, 10 MHz to 40 GHz

The Rohde and Schwarz ZVAX-TRM40 is an advanced extension unit designed to enhance the capabilities of network analyzers, particularly for testing T/R modules, receivers, transceivers, and power amplifiers. It operates within a frequency range of 10 MHz to 40 GHz and integrates seamlessly with the R&S ZVA and R&S ZVT series vector network analyzers.

Key Features

• Wide Frequency Range: Supports a broad frequency range from 10 MHz to 40 GHz, suitable for a variety of high-frequency applications.
• High Power Test Ports: Equipped with integrated high-power test ports, enabling bidirectional high-power measurements up to +43 dBm.
• Output Amplifiers: Optional output amplifiers can be used to increase the output power at the test ports, compensating for internal losses and matching the performance of the network analyzer’s standard test ports.
• Combiner and Pulse Modulators: Optional combiners allow for the generation of two-tone signals, essential for intermodulation measurements, while pulse modulators enable pulsed signal measurements.
• Customizable Configurations: Users can tailor the unit with various hardware options to meet specific measurement requirements, including low-noise pre-amplifiers and combiners for advanced signal conditioning.
• Seamless Integration: Designed to integrate with R&S ZVA and R&S ZVT network analyzers, providing a cohesive and powerful measurement setup.

Technical Specifications

• Frequency Range: 10 MHz to 40 GHz
• Maximum Output Power: Up to +43 dBm
• Measurement Capabilities: Supports pulsed signal measurements, two-tone signal generation, and advanced signal conditioning
• Interfaces: Compatible with R&S ZVA and R&S ZVT series network analyzers

This unit is in good working condition and is tested to OEM critical specifications. Comes with a 30 day warranty, and we also offer a 7 day right of return (restocking fee may apply). We have been in business for over 25 years, our main focus is customer satisfaction by providing the highest quality of new or used test equipment. Please let us know if you have any questions.

We offer fast domestic and international shipping. We can ship on your FedEx, UPS, or DHL account upon request.  Lead time is typically 1-3 business days. Overseas customers, please consider duty’s and taxes before purchasing

We accept PayPal, Credit Cards, Wire Transfers, Checks, and NET Terms (select and approved customers only).
