Keysight 53230A 350 MHz Universal Frequency Counter/Timer, 12 digits/s, 20 ps

The Keysight 53230A is a high-performance universal frequency counter/timer designed for precise frequency, time interval, and pulse parameter measurements. With a frequency range up to 350 MHz and an impressive resolution of 12 digits per second, this instrument is ideal for a wide range of applications in R&D, manufacturing, and calibration labs. The 53230A offers advanced features such as continuous gap-free measurements, timestamping, and a built-in optional pulse/burst microwave frequency extension, making it a versatile tool for accurate and reliable measurements.

Key Features:

1. High Frequency Range:
   • Measures frequencies up to 350 MHz with high accuracy.
   • Suitable for a wide range of applications including RF and microwave signal analysis.
2. High Resolution:
   • Provides 12 digits/s resolution for precise frequency measurements.
   • Time interval measurements with 20 ps single-shot resolution.
3. Advanced Measurement Capabilities:
   • Continuous gap-free measurements for accurate frequency and time interval analysis.
   • Timestamping and histograms for detailed signal characterization.
   • Built-in optional pulse/burst microwave frequency extension for extended measurement range.
4. User-Friendly Interface:
   • Intuitive graphical display and easy-to-navigate menus for efficient operation.
   • Large color LCD for clear visibility of measurement data and results.
5. Flexible Connectivity:
   • Multiple communication interfaces including USB, LAN, and GPIB for seamless integration into automated test systems.
   • Supports remote control and data logging for enhanced operational flexibility.
6. Comprehensive Analysis Tools:
   • Includes statistical analysis, Allan deviation, and trend plot capabilities.
   • Built-in math functions and limit testing for detailed analysis and testing.
7. Robust and Reliable Design:
   • Durable construction ensures long-term reliability and consistent performance in demanding testing environments.
   • Designed to withstand rigorous use in both laboratory and field settings.

Technical Specifications:

• Frequency Range: DC to 350 MHz (standard); up to 15 GHz with optional microwave channel
• Resolution: 12 digits/s (frequency); 20 ps single-shot (time interval)
• Measurement Functions: Frequency, period, time interval, rise/fall time, pulse width, duty cycle, phase, and more
• Connectivity:
  • USB 2.0
  • LAN (Ethernet 10/100Base-T)
  • GPIB
• Display: Large color LCD
• Statistics: Mean, min, max, standard deviation, Allan deviation
• Math Functions: Offset, scaling, ratio, sum, difference
• Power Supply: 100-240 VAC, 50/60 Hz
• Dimensions: 88 mm x 212 mm x 348 mm
• Weight: Approximately 4.5 kg

This unit is in good working condition and is tested to OEM critical specifications. Comes with a 30 day warranty, and we also offer a 7 day right of return (restocking fee may apply). We have been in business for over 25 years, our main focus is customer satisfaction by providing the highest quality of new or used test equipment. Please let us know if you have any questions.

We offer fast domestic and international shipping. We can ship on your FedEx, UPS, or DHL account upon request.  Lead time is typically 1-3 business days. Overseas customers, please consider duty’s and taxes before purchasing

We accept PayPal, Credit Cards, Wire Transfers, Checks, and NET Terms (select and approved customers only).
