Tektronix BSA175C BERTScope 17.5 Gb/s Bit Error Rate Analyzer

The Tektronix BSA175C is a high-performance Bit Error Rate Tester (BERT) designed to support data rates up to 17.5 Gb/s. It is part of the BERTScope series, providing comprehensive signal integrity testing and characterization for high-speed digital communication systems. The BSA175C enables detailed bit error rate detection and analysis, making it a vital tool for engineers and technicians.

Key Features:

• High Data Rate Support: Capable of testing data rates from 1 Gb/s to 17.5 Gb/s, suitable for a wide range of high-speed communication standards.
• Accurate Jitter Measurement: Supports Total Jitter (TJ), Random Jitter (RJ), and Deterministic Jitter (DJ) measurements compliant with industry standards.
• Advanced Error Analysis: Provides deep error analysis capabilities, allowing users to isolate and debug problematic bit and pattern sequences.
• Flexible Clocking: Features a generator clock path with adjustable modulation options for Spread Spectrum Clocking (SSC) and supports sub-rate system clocks.
• Mask Compliance Testing: Enables detailed mask compliance contour testing, essential for standards such as XFP/XFI and OIF CEI.
• PatternVu Option: Includes advanced features like a software-implemented FIR filter for viewing eye diagrams after receiver equalization and CleanEye for removing nondeterministic jitter components.

Technical Specifications:

• Data Rate: 1 Gb/s to 17.5 Gb/s
• Clock Outputs: 1-17.5 GHz, with sub-rate clock outputs ranging from 0.250 to 3.575 GHz
• Jitter Analysis:
  • Sinusoidal Jitter (SJ): Internal frequency ranges from 1 kHz to 100 MHz
  • Total Jitter (TJ): Measures TJ including all jitter components
  • Random Jitter (RJ) and Deterministic Jitter (DJ): Separately measured
• Pattern Generation:
  • Memory depth: Flexible memory sequencing with two levels of loop nesting and up to 1 million iterations per loop
  • PatternVu: FIR filter implementation for eye diagram visualization post-equalization
• Mask Testing:
  • Depth advantage for eye diagrams, sampling every point on the perimeter of the mask
  • Compliance Contour view for mask overlay on measured BER contours
• Clock Recovery: Compatible with Tektronix CR125A, CR175A, and CR286A clock recovery instruments, ensuring accurate jitter measurement with compliant clock recovery
