Tektronix BA1600

The Tektronix BA1600 Bit Error Rate Analyzer (BERT) is a highly advanced instrument designed for testing and analyzing high-speed digital communication systems. This model supports data rates up to 1.6 Gb/s, making it ideal for a wide range of applications in signal integrity testing and bit error rate measurements.

Key Features:

• High-Speed Data Rates: Capable of pattern generation and error detection at speeds up to 1.6 Gb/s.
• Integrated Eye Diagram Analysis: Features BER-correlated eye diagram analysis with pass/fail masks to provide a visual representation of signal integrity.
• Comprehensive Error Analysis: Offers advanced error analysis including Error Mapping analysis (MAP) and Error Correction Coding emulation (ECC).
• ANSI Jitter Measurements: Performs detailed jitter analysis, including Random Jitter (RJ), Deterministic Jitter (DJ), and Total Jitter (TJ).
• BER Contour Analysis: Measures and views the eye diagram opening as a function of BER, providing a quick understanding of signal integrity.

Technical Specifications:

• Data Rate: Up to 1.6 Gb/s
• Pattern Generation: Supports various pseudo-random binary sequence (PRBS) patterns for comprehensive testing.
• Eye Diagram: Integrated with BER-contoured masks for precise signal integrity analysis.
• Jitter Analysis: Supports ANSI jitter measurements and BER contour with automatic mask creation.
• Connectivity: Interfaces for easy integration into various testing setups.

This unit is in good working condition and is tested to OEM critical specifications. Comes with a 30 day warranty, and we also offer a 7 day right of return (restocking fee may apply). We have been in business for over 25 years, our main focus is customer satisfaction by providing the highest quality of new or used test equipment. Please let us know if you have any questions.

We offer fast domestic and international shipping. We can ship on your FedEx, UPS, or DHL account upon request.  Lead time is typically 1-3 business days. Overseas customers, please consider duty’s and taxes before purchasing

We accept PayPal, Credit Cards, Wire Transfers, Checks, and NET Terms (select and approved customers only).
