Tektronix 370A Programmable Curve Tracer

The Tektronix 370A is a high-resolution programmable curve tracer used for DC parametric characterization of various semiconductor devices such as transistors, thyristors, diodes, SCRs, MOSFETs, optoelectronic components, solar cells, and solid-state displays. It is widely used in research and development, manufacturing, and quality control for its precision and versatility.

Key Features:

• High Precision Measurements: Capable of sourcing up to 2000 volts or 10 amps, and handling up to 220 watts.
• Measurement Resolution: 1 nanoamp measurement resolution and 2 millivolt voltage measurement resolution.
• Waveform Analysis: Includes features like waveform comparison, envelope display, waveform averaging, and dot cursor for detailed analysis.
• Kelvin Sense Measurements: Ensures accurate voltage measurements by eliminating lead resistance.
• Programmable: Fully programmable via GPIB for automated testing.
• Data Storage: Equipped with 3.5-inch MS DOS-compatible disk storage for saving and recalling setups.
• Interactive Control: Full-featured front panel or remote control over GPIB interface.

Technical Specifications:

• Modes: AC, ±DC, ±Leakage, ±Rectified Sine
• Current Range:
  • 16V mode: 10A peak, 20A pulsed
  • 80V mode: 2A peak, 4A pulsed
  • 400V mode: 0.4A peak, 0.8A pulsed
  • 2000V mode: 0.05A peak, 0.1A pulsed
• Step Generator:
  • Modes: Stair step (DC, 80 µs pulse, 300 µs pulse)
  • Range: 50 nA to 200 mA (current), 50 mV to 2V (voltage)
• Measurement Characteristics:
  • Collector current: 100 nA/div to 2 A/div
  • Emitter current: Up to 10X step amplitude

This unit is in good working condition and is tested to OEM critical specifications. Comes with a 30 day warranty, and we also offer a 7 day right of return (restocking fee may apply). We have been in business for over 25 years, our main focus is customer satisfaction by providing the highest quality of new or used test equipment. Please let us know if you have any questions.

We offer fast domestic and international shipping. We can ship on your FedEx, UPS, or DHL account upon request.  Lead time is typically 1-3 business days. Overseas customers, please consider duty’s and taxes before purchasing

We accept PayPal, Credit Cards, Wire Transfers, Checks, and NET Terms (select and approved customers only).
