Rohde and Schwarz ZNLE4 Vector Network Analyzer, 1 MHz to 4.5 GHz, Two Ports

The Rohde and Schwarz ZNLE4 is a highly compact and efficient vector network analyzer (VNA) designed for a wide range of applications in the frequency range from 1 MHz to 4.5 GHz. This two-port VNA is ideal for bidirectional measurements of S-parameters (S11, S21, S12, and S22) on passive components, making it a valuable tool in telecommunications, aerospace, and electronics testing environments.

Key Features

• Wide Frequency Range: Covers a range from 1 MHz to 4.5 GHz, with an optional extension to 100 kHz.
• Compact Design: Lightweight and space-saving, with an instrument depth of less than 24 cm and a weight of around 6 kg.
• High Accuracy: Offers low trace noise (typical 0.001 dB at 10 kHz measurement bandwidth) for highly accurate and stable measurements.
• Fast Measurements: Up to 10 times faster than comparable instruments, enabling quick and efficient data acquisition.
• Standalone Operation: Fully integrated PC platform running Windows 10, eliminating the need for an external PC.
• User-Friendly Interface: Features a large 10.1” touchscreen with multi-touch capabilities for easy operation and navigation.
• Flexible Configuration: Includes options for GPIB interface, time domain analysis, and distance-to-fault measurements.

Technical Specifications

• Frequency Range: 1 MHz to 4.5 GHz (extendable to 100 kHz with option ZNLE-B100)
• Number of Ports: 2
• Connectors: N-type (f)
• Dynamic Range: Up to 120 dB (typical)
• Output Power: Up to 0 dBm
• IF Bandwidth: 1 Hz to 500 kHz
• Measurement Speed: Fast sweep times and low measurement noise

This unit is in good working condition and is tested to OEM critical specifications. Comes with a 30 day warranty, and we also offer a 7 day right of return (restocking fee may apply). We have been in business for over 25 years, our main focus is customer satisfaction by providing the highest quality of new or used test equipment. Please let us know if you have any questions.

We offer fast domestic and international shipping. We can ship on your FedEx, UPS, or DHL account upon request.  Lead time is typically 1-3 business days. Overseas customers, please consider duty’s and taxes before purchasing

We accept PayPal, Credit Cards, Wire Transfers, Checks, and NET Terms (select and approved customers only).
