Rohde and Schwarz ZNBT20 Vector Network Analyzer, 8 Ports, 20GHz

The Rohde and Schwarz ZNBT20 Vector Network Analyzer is a highly versatile and powerful tool designed for multiport network analysis. Operating from 100 kHz to 20 GHz, this VNA is engineered to deliver superior performance and precision in both development and production settings. With its 8 ports, the ZNBT20 is ideal for testing multiple devices under test (DUTs) simultaneously, significantly enhancing throughput and efficiency in various applications including wireless communications, automotive, and aerospace industries.

Key Features

• Frequency Range: 100 kHz to 20 GHz, accommodating a wide range of testing requirements from RF to microwave frequencies.
• Multi-Port Capability: Equipped with 8 ports, facilitating complex measurements and supporting high-volume testing scenarios.
• High Dynamic Range: Offers a dynamic range of up to 140 dB, ensuring accurate and reliable measurements.
• Compact Design: Space-saving architecture suitable for automated production environments, with remote control capabilities via external monitor, mouse, and keyboard or touchscreen.
• Fast Measurement Speed: Short sweep times, making it suitable for high-throughput testing applications.
• Application Versatility: Supports various applications including Bluetooth, WLAN, GPS, and other wireless communication technologies.

Technical Specifications

• Frequency Range: 100 kHz to 20 GHz
• Ports: 8
• Dynamic Range: Up to 140 dB
• Output Power: -85 to 10 dBm
• Power Sweep Range: 100 dB
• IF Bandwidth: 1 Hz to 10 MHz
• Harmonics: <-30 dBc
• Port Connectors: N Type – Female
• Port Impedance: 50 Ohms
• Dimensions: 462 mm × 238 mm × 611 mm (18.2 in × 9.4 in × 24.1 in)
• Weight: 38 kg (83.8 lb)

This unit is in good working condition and is tested to OEM critical specifications. Comes with a 30 day warranty, and we also offer a 7 day right of return (restocking fee may apply). We have been in business for over 25 years, our main focus is customer satisfaction by providing the highest quality of new or used test equipment. Please let us know if you have any questions.

We offer fast domestic and international shipping. We can ship on your FedEx, UPS, or DHL account upon request.  Lead time is typically 1-3 business days. Overseas customers, please consider duty’s and taxes before purchasing

We accept PayPal, Credit Cards, Wire Transfers, Checks, and NET Terms (select and approved customers only).
