Rohde and Schwarz SMB100B

The Rohde and Schwarz SMB100B is a high-performance analog RF signal generator designed for a wide range of applications including research and development, production, and maintenance. It covers a broad frequency range from 8 kHz to 1 GHz, 3 GHz, or 6 GHz, making it suitable for various RF and microwave testing environments.

Key Features

• Wide Frequency Range: Available in configurations that cover 8 kHz to 1 GHz, 3 GHz, or 6 GHz.
• High Output Power: Delivers up to +34 dBm at 1 GHz without requiring an external amplifier.
• Spectral Purity: Outstanding single sideband (SSB) phase noise performance of less than -134 dBc at 1 GHz and 20 kHz offset, ensuring high signal quality.
• Modulation Capabilities: Supports AM, FM, and pulse modulation, providing flexibility for different testing needs.
• User-Friendly Interface: Features a 7-inch capacitive touch color display for intuitive operation and control.
• Compact Design: The benchtop unit has a 2 HU form factor and ¾ 19″ width, making it ideal for use in space-constrained environments.

Technical Specifications

• Frequency Range: 8 kHz to 1 GHz, 3 GHz, or 6 GHz
• Output Power: Up to +34 dBm
• SSB Phase Noise: -146 to -110 dBc/Hz
• Modulation Types: AM, FM, Pulse
• Impedance: 50 Ohms
• Interfaces: Ethernet, GPIB, Serial RS-232, USB
• Connectors: BNC, N Type, SMA (all female)
• Dimensions: 344 mm × 108 mm × 372 mm (13.6 in × 4.3 in × 14.7 in)
• Weight: 6.8 kg (15.0 lb)
• Power Requirements: 100 V to 240 V, 110 W
• Operating Temperature: 0 to 55°C
• Storage Temperature: -40 to 71°C

This unit is in good working condition and is tested to OEM critical specifications. Comes with a 30 day warranty, and we also offer a 7 day right of return (restocking fee may apply). We have been in business for over 25 years, our main focus is customer satisfaction by providing the highest quality of new or used test equipment. Please let us know if you have any questions.

We offer fast domestic and international shipping. We can ship on your FedEx, UPS, or DHL account upon request.  Lead time is typically 1-3 business days. Overseas customers, please consider duty’s and taxes before purchasing

We accept PayPal, Credit Cards, Wire Transfers, Checks, and NET Terms (select and approved customers only).
