Keysight DSAV164A Infiniium V-Series Oscilloscope: 16 GHz, 4 Analog Channels

The Keysight DSAV164A Infiniium V-Series Oscilloscope is a high-performance instrument designed to deliver exceptional signal integrity and advanced analysis capabilities. With a bandwidth of 16 GHz and four analog channels, this oscilloscope is ideal for capturing and analyzing high-speed signals in demanding R&D and testing environments. The DSAV164A offers a comprehensive suite of features, making it an indispensable tool for engineers and researchers working with cutting-edge technologies.

Key Features:

1. High Bandwidth and Sampling Rate:
   • Provides 16 GHz bandwidth for capturing high-speed signals with precision.
   • Offers up to 80 GS/s sampling rate on all four channels, ensuring detailed signal representation.
2. Exceptional Signal Integrity:
   • Low noise floor and high dynamic range for accurate measurements.
   • Advanced acquisition and processing capabilities to maintain signal fidelity.
3. Advanced Analysis Capabilities:
   • Comprehensive set of analysis tools including jitter analysis, eye diagrams, and protocol decoding.
   • Automated measurements and advanced triggering options to quickly identify and analyze signal anomalies.
4. User-Friendly Interface:
   • Large, high-resolution touch screen for intuitive operation and easy navigation.
   • Customizable display options to suit individual preferences and workflow.
5. Enhanced Connectivity:
   • Multiple communication interfaces including USB, LAN, and GPIB for flexible connectivity.
   • Supports remote control and monitoring for enhanced operational flexibility.
6. Powerful Software Integration:
   • Compatible with Keysight’s advanced software tools for enhanced data analysis, visualization, and reporting.
   • Supports various software packages for specialized analysis and application-specific needs.
7. Robust and Reliable:
   • Durable design to withstand rigorous use in various testing environments.
   • Reliable operation ensuring consistent performance over extended periods.

Technical Specifications:

• Bandwidth: 16 GHz
• Sampling Rate: Up to 80 GS/s on all four channels
• Channels: 4 analog channels
• Memory Depth: Up to 2 Gpts per channel
• Rise Time: < 28 ps
• Vertical Resolution: 8 bits (up to 12 bits with high-resolution mode)
• Input Impedance: 50 ?
• Maximum Input Voltage: ±5 V (DC + peak AC)
• Connectivity: USB 2.0, LAN (Ethernet 10/100/1000Base-T), GPIB, HDMI
• Display: 15.6-inch high-resolution capacitive touch screen
• Dimensions: 426 mm x 285 mm x 160 mm
• Weight: Approximately 13.6 kg

This unit is in good working condition and is tested to OEM critical specifications. Comes with a 30 day warranty, and we also offer a 7 day right of return (restocking fee may apply). We have been in business for over 25 years, our main focus is customer satisfaction by providing the highest quality of new or used test equipment. Please let us know if you have any questions.

We offer fast domestic and international shipping. We can ship on your FedEx, UPS, or DHL account upon request.  Lead time is typically 1-3 business days. Overseas customers, please consider duty’s and taxes before purchasing

We accept PayPal, Credit Cards, Wire Transfers, Checks, and NET Terms (select and approved customers only).
