Keysight (Agilent) TBS2074 70 MHz, 1 GS/s, 20 M Record Length, 4-Channel Digital Storage Oscilloscope

The Keysight (Agilent) TBS2074 Digital Storage Oscilloscope is a versatile, high-performance instrument designed for capturing and analyzing electrical signals with exceptional accuracy and ease. Featuring a bandwidth of 70 MHz, a sampling rate of 1 GS/s, and a 20 M record length, this oscilloscope is ideal for a wide range of applications, including troubleshooting, design verification, and educational purposes. The TBS2074 combines advanced features, user-friendly operation, and robust construction, making it an essential tool for engineers, technicians, and educators.

Key Features:

1. Moderate Bandwidth and High Sampling Rate:
   • 70 MHz bandwidth for capturing moderate-frequency signals.
   • 1 GS/s sampling rate for detailed signal analysis.
2. Four Independent Channels:
   • Four analog channels for simultaneous signal capture and comparison.
   • Ideal for analyzing multiple signals in complex circuits.
3. Long Record Length:
   • 20 M record length per channel for capturing long signal sequences.
   • Enables detailed analysis of signal behavior over time.
4. Advanced Triggering Capabilities:
   • Supports edge, pulse width, and video triggering for precise signal capture.
   • Facilitates detailed analysis of specific signal events.
5. Large, High-Resolution Display:
   • 9-inch WVGA color display for clear and detailed waveform visualization.
   • Easy-to-read screen, even in bright environments.
6. User-Friendly Interface:
   • Intuitive controls and menu navigation for simple operation.
   • Built-in help and setup guides for ease of use.
7. Data Storage and Connectivity:
   • Internal memory and USB ports for data storage and transfer.
   • Compatible with PC software for extended data analysis and reporting.
8. Math and Analysis Functions:
   • Includes functions such as FFT, addition, subtraction, multiplication, and division for advanced waveform analysis.
   • Allows detailed examination of signal characteristics and behavior.
9. Portable and Compact Design:
   • Lightweight and compact form factor for easy integration into test setups.
   • Portable for convenient use in both laboratory and field environments.
10. Robust and Durable Construction:
    • Built with high-quality materials to withstand rigorous use.
    • Designed for long-term reliability and durability.

Technical Specifications:

• Bandwidth: 70 MHz
• Sampling Rate: 1 GS/s
• Channels: 4 analog channels
• Record Length: 20 Mpts per channel
• Display: 9-inch WVGA color display
• Trigger Types: Edge, pulse width, video
• Connectivity: USB host, USB device
• Math Functions: FFT, addition, subtraction, multiplication, division
• Dimensions: 285 mm x 152 mm x 70 mm
• Weight: Approximately 2.3 kg
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to +70°C

This unit is in good working condition and is tested to OEM critical specifications. Comes with a 30 day warranty, and we also offer a 7 day right of return (restocking fee may apply). We have been in business for over 25 years, our main focus is customer satisfaction by providing the highest quality of new or used test equipment. Please let us know if you have any questions.

We offer fast domestic and international shipping. We can ship on your FedEx, UPS, or DHL account upon request.  Lead time is typically 1-3 business days. Overseas customers, please consider duty’s and taxes before purchasing

We accept PayPal, Credit Cards, Wire Transfers, Checks, and NET Terms (select and approved customers only).
